Custom High-Speed LVDS Cable Harness (JAE FI-X30HL To JST SHDR-40V-S-B)

When a high-end industrial display equipment manufacturer was developing a 10.1-inch industrial touch all-in-one machine, it faced challenges such as unstable signal transmission between the main board and the LCD screen, poor anti-interference performance, and limited assembly space. We customized a high-speed LVDS cable harness from JAE FI-X30HL to JST SHDR-40V-S-B for them, providing a one-stop connection solution.

1. Mismatched interfaces between the main board and the screen end, making standard wires incompatible.
2. Screen flickering, noise, and frame loss in a strong electromagnetic environment.
3. Compact internal space of the equipment, requiring thin and bend-resistant wires.
4. 24/7 operation on industrial sites, requiring high reliability and long service life.

• Precisely connect JAE FI-X30HL (screen end) and JST SHDR-40V-S-B (main board end), with 1:1 custom pin definition for plug-and-play use.
• Adopt differential twisted pair + shielding structure for LVDS high-speed transmission, anti-EMI interference, and no screen tearing or delay.
• Ultra-fine flexible wires, bend-resistant and high-temperature resistant, suitable for wiring in narrow spaces.
• Full-process quality control, passing continuity, impedance, aging, and plug-in tests, stably adapting to industrial scenarios.

• Clear and stable display quality, with zero faults during 6000+ hours of continuous operation.
• Assembly efficiency increased by 40%, and defective rate reduced to below 0.3%.
• Bulk delivery, supporting small-batch trial production and large-scale mass production.

Industrial all-in-one machines, in-vehicle central controls, medical displays, industrial control screens, high-end laptops, embedded display systems.
